Welcome to Wuxi Changrong Conveying Machinery Co.,Ltd. Website!
Hotline:0510-8338 0342FavoriteContact
Product
ProductPosition:Home > Product
Vibrating conveyor
Model description of vibrating conveyor
 GZG-Inertial vibrating feeder
 XXX Feed chute width
For example, gzg450 is a closed inertial vibrating feeder with a feed groove width of 450mm, a light groove type and a four pole vibrator.
GZG series self synchronous inertial vibrating feeder is a feeding equipment with advanced economic indicators. It is widely used in metallurgy, mining, coal, building materials, light industry, chemical industry, electric power, grain and other departments to put blocks in crushers, sorting machinery, screening equipment, transportation machinery and packaging machinery Granular materials are uniformly, continuously or quantitatively fed to the receiving device from the storage bin or funnel. GZG series feeders are ordinary trough feeders, which are used for feeding materials without special requirements. GZG series feeders are closed trough feeders, which are used for feeding materials with large dust and volatile materials.
Components of vibrating conveyor
It is composed of rectangular groove or circular groove, vibration motor and elastic support. The size and conveying capacity can be customized according to customer requirements, and the cooling function can also be added in the conveying process.
Customization Description: the equipment can be customized according to customer requirements.
Common models of vibrating conveyor:
產(chǎn)品Model Handling materials Conveying capacity(m3/h) Center distance between inlet and outlet(mm) Total length(mm) Motor power(KW)
CRGZG200 Chemical powder 2 1460mm 2057mm 0.37kw
CRGZG250 Cobalt oxide powder 3 1300mm 1470mm 0.4kw
CRGZG300 catalyzer 1-10 1000mm 1500mm 0.25kw
CRGZG350 Sintered ceramsite 12 5100mm 5600mm 1.5kw
CRGZG450 pet food 30-40 8000mm 8354mm 2.2kw
CRGZG800 Powder 1-9 5500mm 6330mm 1.1kw
CRGZG900 Wet slag 1 4200mm 5380mm 1.5KW
CRGZG1500 Wheat 13 8000mm 9000mm 2.2KW
